Automatic Corrugation Plant – 3 Ply Unit space
Nagjan offers exclusive range of Automatic Corrugation plants. 3 Ply Automatic Corrugation Plant comes under this range. These automated plants ensure high strength, better efficiency & Productivity, durability and reliable performance. Equipped with all the latest tools & machines, the offered range is manufactured in-house using quality raw materials. Our range is known for high performance, robust construction, longer life and sturdiness. These plants are made according to custom specifications.
Technical Specification
- The upper – lower Corrugating Rollers are made up of 52 Cr.Mo high quality alloy steel. After heat treatment, the hardness is above HRC 58 – 60 deg. The surface is well grounded and hard chromed.
- The Corrugation Rollers and Pressure Rollers are bearing mounted for smooth running, high speed and durable life.
- Glue is circulated automatically by a Tank and Pump to obtain uniform supply and to avoid stagnation.
- Motorized glue width dividing to match the paper width.
- Idle running motor for Glue Applicator Roller to avoid glue dry.
- Adjustment for gap between Glue Roller & Doctor Roller by electric or manual.
- Oil immersed type lubrication to void noise.
- Corrugation Roller, Pressure Roller and Glue Roller by pneumatic adjustment.
- Corrugated 2Ply sheet taken out by Vacuum suction method & Air control system.
- A, B, C, D, E Flutes can be made as per order.
- Effective width: 1400mm / 1600mm / 1800mm / 2000mm / 2200mm and 2500mm.
- Eddy current motor as Main drive and Independent Gear box.
- Max Speed: 280S – 100metres/minute | 320S – 120metres/minute | 360S – 150metres/minute
| Model | STM-1100 | STM-1300 | STM-1450 | STM-1650C |
|---|---|---|---|---|
| Max Size | 1300 x 1300mm | 1300 x 1300mm | 1450 x 1450mm | 1650 x 1650mm |
| Min Size | 400 x 400mm | 400 x 400mm | 400 x 400mm | 400 x 400mm |
| Max Speed | 6000 Sheets/hour | 6000 Sheets/hour | 6000 Sheets/hour | 6000 Sheets/hour |
| Total Power | 13.5 Kw | 13.5 Kw | 13.5 Kw | 15 Kw |
| Total Weight | 6,500 Kg | 6,500 Kg | 7,000 Kg | 7,800 kg |
| Dimension | 12800x2300x2655mm | 12800x2300x2655mm | 12800x2400x2655mm | 16000x2700x2700mm |
